PULS DIN-Rail Power Supply for 1-phase systems-24V/20A

SKU: QS20.241-A1 Category: Tags: ,

Description

DIN-rail power supplies for 1-phase systems
24V, 20A

  • AC 100-240V wide-range input
  • Width only 82mm
  • Efficiency up to 93.9%
  • 150% (720W) peak load capability
  • Safe Hiccup PLUS overload mode
  • Easy fuse tripping due to high overload current
  • Active power factor correction (PFC)
  • Negligible low inrush current surge
  • Short-term operation down to 60Vac and up to 300Vac
  • Full power between -25°C and +60°C
  • DC-OK relay contact
  • Quick-connect spring-clamp terminals
  • ATEX and IECEx approved
  • conformal coated PC-board
DC Output 24-28Vdc
20-17A
480W
Input AC 100-240V  (± 15%)

Additional information

Input Voltage

AC 100-240V, DC 110-150V

Output Voltage

24V

Output Current

20A

Power

480W
