PULS DIN-Rail Power Supply for 3-phase systems-24V/20A

SKU: QT20.241 Category: Tags: ,

Description

DIN-rail power supplies for 3-phase systems
24V, 20A

  • 3AC 380-480V Wide-range Input
  • Also Specified for 2-Phase Operation
  • Extra Long Lifetime
  • 95% Full Load and Excellent Partial Load Efficiencies
  • Width only 65mm, Weight only 870g
  • 50% BonusPower®, 720W for up to 4s
  • Active Power Factor Correction PFC
  • Active Filtering of Input Transients
  • Full Power Between -25°C and +60°C
  • Extremely Low Input Inrush Current Surge
  • DC-OK Relay Contact
  • Quick-connect Spring-clamp Terminals
DC Output 24-28Vdc
20-17.5A
480W
Input AC 380-480V  (± 15%)
Size (WxHxD) 65 x 124 x 127mm
Weight 870g

Additional information

Input Voltage

AC 380-480V

Output Voltage

24V

Output Current

20A

Power

480W
